Kingston DC2000B 960GB M.2 2280 PCIe Gen 4×4 NVMe SSD

Kingston’s DC2000B SSD is a high-performance boot drive designed for data centers using the latest Gen 4×4 PCIe interface with 3D TLC NAND. With low latency, IOPS consistency and hardware-based power loss protection, it ensures reliability and efficiency. Available in capacities of up to 960GB, it’s ideal for enterprise server boot and caching applications

Add to wishlist
SKU: SEDC2000BM8/960G Categories: , Tags: , , , , ,

Description



 Specifications

Capacity 960GB
Form Factor M.2 2280
Interface PCIe 4.0 x4 NVMe
NAND 3D TLC
Sequential Read/Write 7000 MB/s / 1300 MB/s
Steady-State 4K Read/Write 540,000 / 47,000 IOPS
Total Bytes Written (TBW) 700 TBW
Latency Read (Average) 70 µs
Latency Write (Average) 20 µs
Power Loss Protection (PLP) Yes
Enterprise SMART Tools
  • Reliability tracking
  • Usage statistics
  • SSD life remaining
  • Wear leveling
  • Temperature monitoring
Endurance 0.4 DWPD (Drive Writes Per Day) over 5 years
Power Consumption
  • Average Read: 3.26W
  • Average Write: 7.36W
  • Max Read: 3.36W
  • Max Write: 7.80W
Operating Temperature 0°C to 70°C
Storage Temperature -40°C to 85°C
Dimensions (L x W x H) 80mm x 22mm x 8.3mm
Weight 11g
Vibration (Non-Operating) 20G Peak (10–2000Hz)
MTBF (Mean Time Between Failures) 2 million hours
Warranty Limited 5-year warranty with free technical support
Additional Features
  • Integrated aluminum heatsink
  • Designed for data center environments



Additional information

Model

DC2000B
Form Factor

Interface

PCIe 4.0 x4 NVMe
