Description
Hardware Specifications
| CPU | Realtek RTD1619B, Quad-Core 1.7 GHz, 64-bit |
|---|---|
| System Memory | 1 GB DDR4 non-ECC |
| Drive Bays | 1 |
| Supported Drive Types | 3.5″ SATA HDD, 2.5″ SATA SSD (with optional 2.5″ Disk Holder) |
| Hot Swappable Drive | No |
| RJ-45 1GbE LAN Port | 1 |
| USB 3.2 Gen 1 Ports | 2 |
| Size (H x W x D) | 166 mm x 71 mm x 224 mm |
| Weight | 0.7 kg |
| System Fan | 1 x 60 mm x 60 mm |
| Fan Speed Modes | Full-Speed Mode, Cool Mode, Quiet Mode, Low-power Mode |
| Brightness Adjustable Front LED Indicators | Yes |
| Power Recovery | Yes |
| Noise Level | 19.0 dB(A) |
| Scheduled Power On / Off | Yes |
| Wake on LAN / WAN | Yes |
| Power Supply Unit / Adapter | 36 watts |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 10.69 watts (Access), 3.44 watts (HDD Hibernation) |
| British Thermal Unit | 36.50 BTU/hr (Access), 11.75 BTU/hr (HDD Hibernation) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certifications | FCC, CE, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, BIS |
| Warranty | 2-year hardware warranty, extendable to 4 years with Extended Warranty Plus |
| Environment | RoHS Compliant |
| Packaging Content | Main Unit x1, Accessory Pack x1, AC Power Adapter x1, RJ-45 LAN Cable x1, Quick Installation Guide x1 |
| Optional Accessories | Plus Series 3.5″ SATA HDD: HAT3300 Series |
Software Specifications
| Operating System | Synology DiskStation Manager (DSM) |
|---|---|
| File Systems | Internal Drives: Btrfs, EXT4 External Drives: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT |
| RAID Support | Basic |
| Network Protocols | SMB, FTP, iSCSI, NFS, WebDAV, SSH, AFP, Telnet, SNMP, HTTPS, CalDAV, SSL/TLS, TCP, LDAP, L2TP, TFTP, IPSec, NFSv3, NFSv4, NFSv4.1, SMB 3.0, CIFS, SMB 2.0, SMB 1.0 |
| Security Features | Hardware encryption, Link Aggregation, Failover protection, Wake on LAN/WAN, SSD trim, Synology Hybrid RAID, RAID migration, NFS Kerberos authentication, Windows ACL, Syslog support, VPN Server, DLNA Media Server |
| IP Camera Support | Up to 12 IP cameras |
| Supported Video Formats | H.264, H.265 |
| Supported Resolutions | 1280×720, 1920×1080, 2048×1536, 2591×1944, 3840×2160 |
| Management Tools | Synology Web Assistant, Cloud Station Drive, Cloud Station Backup, Cloud Sync Decryption Tool, Evidence Integrity Authenticator, Photo Station Uploader, Snapshot Manager for VMware, Snapshot Manager for Windows, NFS Plug-in for VMware VAAI |
