Description
Hardware Specifications
| CPU Model | AMD Ryzen V1500B |
|---|---|
| CPU Architecture | 64-bit |
| CPU Frequency | 4-core 2.2 GHz |
| Hardware Encryption Engine (AES-NI) | Yes |
| System Memory | 4 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 4 GB (4 GB x 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB x 2) |
| Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 24 (DX1222 x 1) |
| Compatible Drive Types | 3.5″ SATA HDD, 2.5″ SATA HDD, 2.5″ SATA SSD |
| Hot Swappable Drive | Yes |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Ports | 2 |
| Expansion Ports | 1 x Mini-SAS HD |
| PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
| Internal File Systems | Btrfs, EXT4 |
| External File Systems | Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT |
| Size (H x W x D) | 270 mm x 300 mm x 340 mm |
| Weight | 9.5 kg |
| System Fans | 2 x 120 mm x 120 mm x 25 mm |
| Fan Speed Modes | Full-Speed Mode, Cool Mode, Quiet Mode |
| Power Recovery | Yes |
| Noise Level | 25.2 dB(A) |
| Scheduled Power On / Off | Yes |
| Wake on LAN / WAN | Yes |
| Power Supply Unit / Adapter | 550 W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 59.8 W (Access), 26.18 W (HDD Hibernation) |
| British Thermal Unit | 204.01 BTU/hr (Access), 89.35 BTU/hr (HDD Hibernation) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certifications | FCC, CE, BSMI, VCCI, RCM, UKCA, EAC, KC, UL |
| Warranty | 3-year hardware warranty |
| Environment | RoHS Compliant |
| Packaging Content | Main Unit x1, Accessory Pack x1, AC Power Cord x1, RJ-45 LAN Cable x2, Quick Installation Guide x1 |
| Optional Accessories | DDR4 ECC SODIMM: D4ES02-4G / D4ES02-8G / D4ES01-16G 10GbE Network Interface Cards: E10G21-F2 / E10G18-T2 / E10G18-T1 25GbE Network Interface Cards: E25G21-F2 M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1 M.2 SSD Adapter Cards: M2D20 2.5″ SATA SSD: SAT5200 3.5″ SATA HDD: HAT5300 Expansion Unit: DX1222 MailPlus License Pack Surveillance Device License Pack Virtual DSM License Pack |
Software Specifications
| Operating System | Synology DiskStation Manager (DSM) |
|---|---|
| Maximum Single Volume Size | 200 TB (32 GB memory required), 108 TB |
| Maximum Internal Volume Number | 256 |
| SSD Read / Write Cache | Yes |
| SSD TRIM | Yes |
| RAID Group | Yes |
| Supported RAID Types | Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| RAID Migration | Basic to RAID 1, Basic to RAID 5, RAID 1 to RAID 5, RAID 5 to RAID 6 |
| Volume Expansion with Larger HDDs | RAID 1, RAID 5, RAID 6, RAID 10 |
| Volume Expansion by Adding a HDD | JBOD, RAID 5, RAID 6 |
| Global Hot Spare Supported | RAID 1, RAID 5, RAID 6, RAID 10 |
