Description

Hardware Specifications

CPU	Intel® Xeon® D-1527 4-core 2.2 GHz, Turbo Boost up to 2.7 GHz
Hardware Encryption Engine	Yes (AES-NI)
System Memory	8 GB DDR4 ECC UDIMM (expandable up to 64 GB)
Drive Bays	4 x 3.5″ or 2.5″ SATA HDD/SSD (drives not included)
Maximum Drive Bays with Expansion Unit	16 (with RX1217/RX1217RP)
M.2 Drive Slots	2 (NVMe & SATA)
Hot Swappable Drive	Yes (Note: Hot swappable drive feature is not supported by M.2 SSD slots)
External Ports	2 x USB 3.2 Gen 1 ports
Expansion Port	1 x Infiniband
Form Factor	1U Rackmount
Dimensions (HxWxD)	44 mm x 480 mm x 518.6 mm
Weight	8.16 kg
LAN Ports	4 x 1GbE RJ-45
PCIe Expansion	1 x Gen3 x8 slot (x8 link)
System Fans	2 x (40 x 40 mm)
AC Input Power Voltage	100 V to 240 V AC
Power Frequency	50/60 Hz, single phase
Redundant Power Supply	No
Wake on LAN/WAN	Yes
Scheduled Power On/Off	Yes

Maximum Single Volume Size	108 TB (default memory), up to 200 TB with 32 GB memory
Maximum Internal Volume Number	256
SSD Read/Write Cache	Yes
SSD TRIM	Yes
RAID Group	Yes
Supported RAID Type	RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
RAID Migration	Basic to RAID 1, Basic to RAID 5, RAID 1 to RAID 5, RAID 5 to RAID 6
Volume Expansion with Larger HDDs	RAID F1, RAID 1, RAID 5, RAID 6, RAID 10
Volume Expansion by Adding a HDD	RAID F1, JBOD, RAID 5, RAID 6
Global Hot Spare Supported RAID Type	RAID F1, RAID 1, RAID 5, RAID 6, RAID 10
File Protocol	SMB, AFP, NFS, FTP, WebDAV
Maximum Concurrent SMB/AFP/FTP Connections	1200
Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion)	6000
Windows Access Control List (ACL) Integration	Yes
NFS Kerberos Authentication	Yes
Maximum Local User Accounts	16000
Maximum Local Groups	512
Maximum Shared Folders	512
Maximum Shared Folder Sync Tasks	32
Maximum Hybrid Share Folders	30
Synology High Availability	Yes
Syslog Events per Second	3000
VMware vSphere with VAAI	Yes
Citrix Ready	Yes
OpenStack	Yes
Networking Protocols	SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPS, FTP, SNMP, LDAP, CalDAV
Supported Browsers	Google Chrome, Firefox, Microsoft Edge, Safari
Maximum Number of Concurrent Users	4000 (default memory), up to 6000 with RAM expansion
