Description
Hardware Specifications
| Model | RS1221RP+ |
|---|---|
| CPU | AMD Ryzen V1500B Quad-core 2.2 GHz |
| CPU Architecture | 64-bit |
| Hardware Encryption Engine | Yes (AES-NI) |
| System Memory | 4 GB DDR4 ECC SODIMM (1 x 4 GB), expandable up to 32 GB (2 x 16 GB) |
| Drive Bays | 8 x 3.5″ or 2.5″ SATA HDD/SSD (drives not included) |
| Hot Swappable Drive | Yes |
| Maximum Storage Capacity | Up to 108 TB (18 TB drive x 6) |
| Expansion Support | Up to 12 bays via RX418 expansion unit |
| External Ports | 2 x USB 3.2 Gen 1 Type-A, 1 x eSATA |
| LAN Ports | 4 x 1GbE RJ-45 (supports Link Aggregation and Failover) |
| PCIe Expansion | 1 x PCIe 3.0 x8 slot (x4 link) |
| Wake on LAN/WAN | Yes |
| Scheduled Power On/Off | Yes |
| System Fans | 2 x 40 mm x 40 mm |
| Power Supply | 2 x 250 W (Redundant, hot-swappable) |
| Power Consumption | Approx. 56.2 dB(A) |
| Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Dimensions (HxWxD) | 88 mm x 482 mm x 306.6 mm |
| Weight | 6.9 kg |
| Certifications | FCC, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, UL, RoHS |
| Warranty | 3 Years |
Software Specifications
| Operating System | DiskStation Manager (DSM) |
|---|---|
| File System |
|
| RAID Types | Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, Synology Hybrid RAID |
| Maximum Single Volume Size | 108 TB |
| Maximum Internal Volumes | 64 |
| Snapshot Replication | Yes |
| Virtualization | VMware vSphere, Microsoft Hyper-V, Citrix XenServer, OpenStack |
| Surveillance Station | Supports up to 40 IP cameras |
| Security Features | Self-Encrypting Drive (SED) support, Snapshot Replication, Application-aware snapshots, Instant recovery |
| Networking Protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™, L2TP) |
| Supported Browsers | Chrome, Firefox, Edge, Safari (iOS 10+), Chrome (Android 6.0+) |
| Mobile Applications | DS cam (iOS 12.0 or above; Android 8.0 or above) |
| Applications | Surveillance Station, Snapshot Replication, Storage Manager, SAN Manager, Synology Drive, Active Backup for Business, Virtual Machine Manager |
