Description
Specifications
| Capacity | 2 TB (2048 GB) |
|---|---|
| Form Factor | M.2 2280 (single-sided) |
| Interface | PCIe 4.0 ×4, NVMe 2.0 |
| Controller | MaxioTech MAP1602A Falcon Lite (Quad-core 1 GHz, 12 nm) |
| Flash Memory | YMTC 232‑layer TLC (Xtacking 3.0) |
| DRAM | None; uses 32 MB Host Memory Buffer (HMB 3.0) |
| SLC Cache | Dynamic pseudo‑SLC (~280 GB) |
| Sequential Read | Up to 7 400 MB/s |
| Sequential Write | Up to 6 500 MB/s |
| Random Read IOPS | Up to 1 000 000 IOPS |
| Random Write IOPS | Up to 900 000 IOPS |
| Endurance | 1 500 TBW |
| MTBF | 1.5 million hours |
| Warranty | 5‑Year limited |
| Operating Temperature | 0 °C to 70 °C |
| Storage Temperature | −40 °C to 85 °C |
| Shock Resistance | 1 500 G, 0.5 ms, half‑sine |
| Vibration Resistance | 10–2 000 Hz, 1.5 mm / 20 G, 30 min/axis |
| Dimensions | 80 × 22 × 2.45 mm |
| Weight | 6 g |
| PS5 Compatible | Yes |
| Power – Idle / Avg / Max | ~0.8 W / 2.7 W / 3.7 W |
| Key Features | • Blazing PCIe 4.0 performance (7400/6500 MB/s) • Efficient HMB 3.0 + dynamic SLC cache • Up to 40 % less power than DRAM-based Gen 4 SSDs • High endurance and reliability (1500 TBW, 1.5 M‑hour MTBF) • Heatsink variant available; PS5-optimized • Extensive lab-tested compatibility and reliability |
